ALM-32120-TR2G Description
✅ Product Overview ✅ Datasheet ✅ Features ✅ Specs ✅ Applications ✅ Where to Buy ✅ Onzuu Distributor ✅ FAQ ✅ Summary
✅ Product Overview: ALM-32120-TR2G
The ALM-32120-TR2G from Broadcom Limited is a high-performance, integrated Low Noise Amplifier (LNA) module designed for RF front-end applications. Operating in the 700 MHz to 1 GHz frequency range, it features excellent gain, low noise figure, and high P1dB output power, making it ideal for GSM, PCS, W-CDMA, and WiMAX systems. Note: This product is marked as Obsolete but still used in legacy systems.
✅ ALM-32120 Datasheet
- Click to view/download ALM-32120 datasheet (PDF)
- Contains electrical characteristics, pin layout, and layout guidelines.
✅ Key Features
- Frequency Range: 700 MHz to 1 GHz
- Gain: 14.3 dB at 900 MHz
- Noise Figure: 2.5 dB
- P1dB Output Power: 34.4 dBm
- Integrated LNA with bias circuitry
- Operating Voltage: 5V
- Current Consumption: 1.5A
✅ Technical Specifications
| Manufacturer | Broadcom Limited |
|---|---|
| Part Status | Obsolete |
| Frequency Range | 700 MHz ~ 1 GHz |
| P1dB Output | 34.4 dBm |
| Gain | 14.3 dB |
| Noise Figure | 2.5 dB |
| Supply Voltage | 5V |
| Current Consumption | 1.5A |
| RF Type | GSM, PCS, W-CDMA, WiMAX |
| Test Frequency | 900 MHz |
| Mounting Type | Surface Mount |
| Package | 20-SMD Module, No Lead (7x10mm) |
✅ Applications
- GSM and PCS base stations
- W-CDMA front-end modules
- WiMAX receiver modules
- Low noise, high gain RF front-end amplification
🛒 Buy ALM-32120-TR2G or Find Alternatives
Looking for ALM-32120-TR2G or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
✅ Why Choose Onzuu as Your Distributor
Onzuu is a professional B2B electronic component distributor offering:
- ✅ Real-time stock visibility and fast lead times
- ✅ Competitive B2B pricing with full traceability
- ✅ Obsolete and hard-to-find component sourcing
- ✅ Technical support and datasheet resources
✅ Frequently Asked Questions (FAQ)
Q1: Is ALM-32120-TR2G still in production?
No, this product is obsolete. However, it may still be available through specialty stock or secondary markets like Onzuu.
Q2: What makes ALM-32120 suitable for wireless systems?
Its high gain, low noise figure, and integrated biasing circuitry make it ideal for RF front-end applications in cellular and broadband systems.
Q3: Are there any alternatives to ALM-32120?
Yes, Broadcom and other vendors offer similar LNAs. Please consult Onzuu's technical team for cross-reference options.
✅ Summary
The ALM-32120-TR2G offers a robust solution for RF applications that require high performance LNA modules within 700MHz to 1GHz. Although obsolete, it remains a valued choice for legacy systems. Use Onzuu to locate remaining stock or identify compatible alternatives for your RF design.
Technical specifications
| ECCN | EAR99 | |
| Mounting Type | Surface Mount | |
| Current - Supply | 1.5A | |
| Product Status | Obsolete | |
| Supplier Device Package | 20-MCOB (7x10) | |
| Series | - | |
| Package / Case | 20-SMD Module, No Lead | |
| Voltage - Supply | 5V | |
| REACH Status | REACH Unaffected | |
| Test Frequency | 900MHz | |
| Mfr | Broadcom Limited | |
| Frequency | 700MHz ~ 1GHz | |
| P1dB | 34.4dBm | |
| Noise Figure | 2.5dB | |
| HTSUS | 8542.33.0001 | |
| Package | Tape & Reel (TR) | |
| RF Type | GSM, PCS, W-CDMA, WiMAX | |
| Gain | 14.3dB | |
| Base Product Number | ALM-32120 | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
