HCPL-0931-000E
Digital Isolators Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
HCPL-0931-000E
901-HCPL-0931-000E
Explore HCPL-0931-000E high-speed optocoupler features, datasheet, specs, and applications. Get insights into its GMR technology, isolation voltage, and supply range. Available at Onzuu.com.
HCPL-0931-000E Description
What is HCPL-0931-000E?
The HCPL-0931-000E is a high-speed optocoupler from Broadcom Limited, designed to provide optical isolation in digital circuits. It utilizes GMR (Giant Magnetoresistive) technology, making it ideal for general-purpose, high-speed signal isolation where low propagation delay and high immunity are crucial.
Key Features of HCPL-0931-000E
- High-speed digital optocoupler (up to 110MBd)
- 2 channels with unidirectional transmission
- 2500Vrms isolation voltage
- GMR-based technology for enhanced reliability
- 15kV/μs common mode transient immunity (CMTI)
- Wide supply range: 3V to 5.5V
- Very low pulse width distortion (max 3ns)
- Low propagation delay (tpLH/tpHL: 15ns max)
Technical Specifications
| Manufacturer | Broadcom Limited |
|---|---|
| Series | - |
| Part Status | Active |
| Technology | GMR (Giant Magnetoresistive) |
| Type | General Purpose Optocoupler |
| Isolated Power | No |
| Number of Channels | 2 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 2500Vrms |
| CMTI | 15kV/μs |
| Data Rate | 110MBd |
| Propagation Delay | tpLH/tpHL: 15ns max |
| Pulse Width Distortion | 3ns max |
| Rise / Fall Time | 1ns typical |
| Voltage - Supply | 3V to 5.5V |
| Operating Temperature | -55°C to +125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (3.90mm Width) |
| Supplier Device Package | 8-SO |
Typical Applications
- Digital signal isolation in industrial systems
- High-speed data communication interfaces
- Microcontroller or FPGA isolation
- Switch-mode power supplies
- Motor control and inverters
HCPL-0931-000E Datasheet
You can download the official datasheet from Broadcom’s website or authorized distributors:
Buy HCPL-0931-000E from Trusted Suppliers
- Onzuu Electronics: www.onzuu.com - Professional B2B distributor of optocouplers and semiconductors.
- Also available via Digi-Key, Mouser, and Avnet.
Note: Always verify availability and RoHS compliance before bulk procurement.
Technical specifications
| Inputs - Side 1/Side 2 | 1/1 | |
| Rise / Fall Time (Typ) | 1ns, 1ns | |
| Common Mode Transient Immunity (Min) | 15kV/µs | |
| Product Status | Active | |
| Supplier Device Package | 8-SO | |
| Pulse Width Distortion (Max) | 3ns | |
| Isolated Power | No | |
| Data Rate | 110MBd | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Number of Channels | 2 | |
| Technology | GMR (Giant Magnetoresistive) | |
| Voltage - Supply | 3V ~ 5.5V | |
| REACH Status | REACH Unaffected | |
| Mfr | Broadcom Limited | |
| Channel Type | Unidirectional | |
| Propagation Delay tpLH / tpHL (Max) | 15ns, 15ns | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage - Isolation | 2500Vrms | |
| ECCN | EAR99 | |
| Mounting Type | Surface Mount | |
| Series | - | |
| Type | General Purpose | |
| HTSUS | 8541.49.8000 | |
| Package | Tube | |
| Base Product Number | HCPL-0931 |
