HSMP-3832-TR1G
RF Diodes Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
HSMP-3832-TR1G
284-HSMP-3832-TR1G
Discover Broadcom's HSMP-3832-TR1G PIN diode – a high-performance RF component with 200V peak reverse voltage, 0.3pF low capacitance, and 1A current handling.
HSMP-3832-TR1G Description
🔎 Product Overview
HSMP-3832-TR1G is a high-performance RF PIN diode from Broadcom, designed for use in RF switching, attenuators, and tuning circuits. With low capacitance and low resistance characteristics, it ensures superior signal integrity in high-frequency applications.
📐 Product Parameters
| Manufacturer | Broadcom Limited |
|---|---|
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Diode Type | PIN - 1 Pair Series Connection |
| Voltage - Peak Reverse (Max) | 200V |
| Current - Max | 1 A |
| Capacitance @ Vr, F | 0.3pF @ 50V, 1MHz |
| Resistance @ If, F | 1.5 Ohm @ 100mA, 100MHz |
| Power Dissipation (Max) | 250 mW |
| Operating Temperature | 150°C (TJ) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| Base Product Number | HSMP-3832 |
⚙️ Typical Applications & Key Features
- ✔️ RF Switching Circuits
- ✔️ Low Capacitance High-Frequency Designs
- ✔️ Attenuator Modules
- ✔️ Surface Mount Design – SOT-23 Package
- ✔️ Suitable for Wireless & Mobile Applications
📄 Datasheet
Download the full technical datasheet of HSMP-3832-TR1G to view electrical curves, recommended circuit layouts, and environmental ratings:
➡️ Click to Download HSMP-3832-TR1G Datasheet (PDF)
🔁 Replacement & Alternative Models
- 🔸 HSMP-3832-TR1 / Broadcom (Lower Capacitance Alternative)
- 🔸 HSMP-3832-TR2G / Broadcom (MACOM)
- 🔸 HSMP-3832-BLKG / Broadcom
📦 Related Products from HSMP Series
- 📌 HSMP-3832-TR1 / Broadcom – PIN Diode, 0.25pF, Lower Power
- 📌 HSMP-3832-TR2G / Broadcom – High Isolation RF Diode, Matched Pair
- 📌 HSMP-3832-BLKG / Broadcom – Dual Diode for Balanced Mixers
All HSMP-series diodes are designed and manufactured by Broadcom Limited, a leader in RF and analog semiconductor solutions.
Technical specifications
| Operating Temperature | 150°C (TJ) | |
| Capacitance @ Vr, F | 0.3pF @ 50V, 1MHz | |
| Voltage - Peak Reverse (Max) | 200V | |
| Diode Type | PIN - 1 Pair Series Connection | |
| ECCN | EAR99 | |
| Current - Max | 1 A | |
| Product Status | Obsolete | |
| Resistance @ If, F | 1.5Ohm @ 100mA, 100MHz | |
| Supplier Device Package | SOT-23-3 | |
| Series | - | |
| Power Dissipation (Max) | 250 mW | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| REACH Status | REACH Unaffected | |
| Mfr | Broadcom Limited | |
| HTSUS | 8541.10.0080 | |
| Package | Tape & Reel (TR) | |
| Base Product Number | HSMP-3832 | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
