BAT54CT-7-F (In Stock:2629)

The BAT54CT-7-F is a highly reliable Schottky diode pair manufactured by Diodes Incorporated. Designed with a common cathode configuration, this diode is optimized for fast switching and low forward voltage drop, making it ideal for small signal applications requiring efficient rectification. Packaged in a compact SOT-523 surface mount case, it suits modern electronic designs demanding space-saving components.

Datasheet Module

Download BAT54 Series Datasheet (PDF)

Features

• Schottky diode technology for low forward voltage drop
• 1 Pair Common Cathode configuration
• Maximum DC Reverse Voltage: 30 V
• Average Rectified Current per diode: 200 mA
• Low reverse leakage current: 2 µA @ 25 V
• Fast switching with reverse recovery time of 5 ns
• Small signal operation up to 200 mA at any speed
• Wide operating junction temperature range: -65°C to 125°C
• Compact SOT-523 surface mount package

Specifications Table

Applications

• High-speed switching in small signal circuits
• Low voltage rectification in power supplies
• Protection circuits against voltage spikes
• Battery-operated devices requiring low forward voltage drop
• General-purpose small-signal diode applications
