ZVN2106A
278-ZVN2106A
Explore the ZVN2106A N-Channel MOSFET by Diodes Inc – 60V, 450mA, TO-92 package. Find full specs, datasheet, features, and sourcing options from Onzuu.
1+:$0.49846
10+:$0.39606
30+:$0.32830
100+:$0.29753
500+:$0.25475
1000+:$0.25889
ZVN2106A Description
ZVN2106A N-Channel MOSFET Overview
The ZVN2106A from Diodes Incorporated is an N-Channel MOSFET designed for efficient switching and signal processing in low to medium power applications. With a 60V drain-to-source voltage and a continuous drain current of 450mA, this transistor is ideal for driving loads such as relays, LEDs, and small motors. It offers low RDS(on) for improved power efficiency and is available in a TO-92 package suitable for through-hole mounting.
Datasheet
Download ZVN2106A Datasheet (PDF)
Features
- N-Channel enhancement-mode MOSFET
- High-speed switching
- Low gate threshold voltage: Max 2.4V
- Maximum drain-source voltage: 60V
- Continuous drain current: 450mA (Ta)
- RDS(on): 2 Ohm max @ 1A, 10V
- Input capacitance: 75pF max @ 18V
- Power dissipation: 700mW (Ta)
- TO-92 through-hole package
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Diodes Incorporated |
| Part Status | Active |
| FET Type | N-Channel |
| Drain to Source Voltage (VDS) | 60V |
| Continuous Drain Current (ID) | 450mA (Ta) |
| Drive Voltage | 10V |
| RDS(on) | 2 Ohm @ 1A, 10V |
| Gate Threshold Voltage (VGS(th)) | 2.4V max @ 1mA |
| Max Gate Voltage (VGS) | ±20V |
| Input Capacitance (Ciss) | 75pF @ 18V |
| Power Dissipation | 700mW (Ta) |
| Operating Temperature | -55°C to 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-92 (TO-226AA) |
Application Scenarios
- Signal switching in logic-level circuits
- Relay driver circuits
- DC-DC converter circuits
- LED driver modules
- General low-power switching applications
🛒 Buy ZVN2106A or Find Alternatives
Looking for ZVN2106A or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
Why Choose Onzuu as Your Distributor?
Onzuu is a trusted electronic components distributor offering:
- Original factory-sourced products
- Flexible packaging options (Bulk, Tape & Reel)
- Competitive B2B pricing for manufacturers
- Global shipping with inventory tracking
Frequently Asked Questions (FAQ)
- Q1: What is the maximum voltage ZVN2106A can handle?
- A1: It supports a maximum drain-to-source voltage of 60V.
- Q2: Is ZVN2106A suitable for PWM switching?
- A2: Yes, it supports high-speed switching and is suitable for PWM circuits.
- Q3: Can this MOSFET be used for battery-powered applications?
- A3: Yes, with low RDS(on) and compact package, it’s suitable for battery applications.
Conclusion
The ZVN2106A MOSFET is a reliable and cost-effective component for switching and signal control applications. Whether you're designing compact logic circuits or need a robust solution for load driving, its low gate threshold and TO-92 package make it an excellent choice. For verified sourcing, Onzuu offers original inventory with flexible shipping options and fast delivery.
Technical specifications
| FET Type | N-Channel | |
| Input Capacitance (Ciss) (Max) @ Vds | 75 pF @ 18 V | |
| Product Status | Active | |
| Supplier Device Package | TO-92 | |
| Drain to Source Voltage (Vdss) | 60 V | |
| Power Dissipation (Max) | 700mW (Ta) | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | |
| Technology | MOSFET (Metal Oxide) | |
| REACH Status | REACH Unaffected | |
| Mfr | Diodes Incorporated | |
| Vgs (Max) | ±20V | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| FET Feature | - | |
| ECCN | EAR99 | |
| Mounting Type | Through Hole | |
| Rds On (Max) @ Id, Vgs | 2Ohm @ 1A, 10V | |
| Vgs(th) (Max) @ Id | 2.4V @ 1mA | |
| Series | - | |
| Current - Continuous Drain (Id) @ 25°C | 450mA (Ta) | |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | |
| HTSUS | 8541.21.0095 | |
| Package | Bulk | |
| Base Product Number | ZVN2106 |
