PVT412S-TPBF (In Stock:6)

Solid State Relays
Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
PVT412S-TPBF
183-PVT412S-TPBF
Explore the PVT412S-TPBF solid state relay: features, specs, datasheet, applications, and purchase options. Infineon HEXFET® series SPST-NO SSR for AC/DC load control.
1+:$5.90466
10+:$5.15280
30+:$4.69244
100+:$4.30851
InStock Quantity: 6

PVT412S-TPBF Description

PVT412S-TPBF Overview

PVT412S-TPBF is a high-performance solid state relay (SSR) developed by Infineon Technologies, part of the HEXFET® PVT series. Designed for both AC and DC load control, it features a SPST-NO (1 Form A) configuration and is suitable for industrial, communication, and consumer electronics applications requiring electrical isolation and long-lasting switching reliability.

PVT412S-TPBF

PVT412S-TPBF Datasheet

You can download the official datasheet here:
Download PVT412S-TPBF Datasheet (PDF)

Key Features of PVT412S-TPBF

  • Solid state relay with optical isolation
  • SPST-NO (1 Form A) output configuration
  • Load voltage range: 0 V to 400 V (AC/DC)
  • Output current up to 140 mA
  • Low input drive voltage: 1.2VDC
  • On-state resistance (max): 27 Ω
  • UL certified
  • Surface-mount 6-SMD (7.62mm) Gull Wing package
  • Operating temperature range: -40°C to 85°C

Technical Specifications

Manufacturer Infineon Technologies
Series PVT, HEXFET®
Part Number PVT412S-TPBF
Packaging Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Mounting Type Surface Mount
Circuit Type SPST-NO (1 Form A)
Output Type AC, DC
Input Voltage 1.2 VDC
Load Voltage 0 V ~ 400 V
Load Current 140 mA
On-State Resistance 27 Ω max
Package / Case 6-SMD (0.300", 7.62mm)
Termination Style Gull Wing
Operating Temperature -40°C ~ 85°C
Agency Approval UL
Base Product Number PVT412

Typical Applications

  • Industrial automation
  • Process control systems
  • Microcontroller output switching
  • Communication systems
  • Smart metering
  • Home appliances and energy monitoring

🛒 Buy PVT412S-TPBF or Find Alternatives

Looking for PVT412S-TPBF or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.

📦 Request a Quote

Authorized Distributor Recommendation - Onzuu

Onzuu is a trusted B2B distributor specializing in electronic components. We offer high-quality sourcing, BOM matching, and global logistics for manufacturers and engineers. For PVT412S-TPBF bulk orders or datasheet requests, contact us at www.onzuu.com.

FAQ: Frequently Asked Questions

Q: Is the PVT412S-TPBF suitable for DC switching?
A: Yes, this device supports both AC and DC loads up to 400V, making it versatile for various designs.
Q: What is the input control voltage?
A: The typical input voltage is 1.2VDC, which is ideal for microcontroller-based systems.
Q: Does this part provide galvanic isolation?
A: Yes, it uses an optical coupling method to provide isolation between the input and output sides.
Q: What’s the package type?
A: It comes in a 6-SMD (0.300", 7.62mm) Gull Wing SMT package.

Conclusion

The PVT412S-TPBF is a compact, reliable, and high-voltage solid state relay ideal for modern electronic systems. With wide AC/DC compatibility, optical isolation, and UL certification, it serves engineers and designers looking for robust switching in a surface mount form. Explore more SSRs or contact Onzuu for volume quotes and support.
