75600-02 (In Stock:39)
Selector Switches Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
75600-02
203-75600-02
Explore the Cole Hersee 75600-02 Rocker Switch with 5 positions and 15A DC rating. Get features, specs, datasheet, applications, and purchasing info from Onzuu.
75600-02 Description
Cole Hersee 75600-02 Rocker Switch Overview
The Cole Hersee 75600-02 is a heavy-duty, non-illuminated rocker switch designed for automotive, marine, and industrial applications. With five selectable positions and a 15A DC current rating, this switch is ideal for controlling various circuits in demanding environments.
Datasheet
Access the official datasheet for detailed specifications and electrical/mechanical design:
Features
- 5-position functionality: Off-On-On-On-On
- Rated for 15A at 16V DC
- Non-illuminated design for standard applications
- Wire leads with connector for simple installation
- Panel mount structure ensures stable placement
- Electrical life: up to 20,000 cycles
Specifications
| Manufacturer | Cole Hersee |
|---|---|
| Part Status | Active |
| Type | Standard Rocker Switch |
| Number of Positions | 5 |
| Switch Function | Off-On-On-On-On |
| Current Rating | 15A (DC) |
| Voltage Rating - DC | 16V |
| Illumination | Non-Illuminated |
| Mounting Type | Panel Mount |
| Termination Style | Wire Leads with Connector |
| Electrical Life | 20,000 Cycles |
Application Scenarios
- Automotive dashboards and auxiliary systems
- Industrial machinery control panels
- Marine equipment switches
- Off-road vehicle electrical control
🛒 Buy 75600-02 or Find Alternatives
Looking for 75600-02 or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
Why Choose Onzuu
As a professional distributor of electronic components, Onzuu provides high-quality sourcing for Cole Hersee products. We offer:
- Authentic sourcing with manufacturer traceability
- Bulk order discounts and global logistics
- Dedicated B2B support and consulting
Frequently Asked Questions (FAQ)
- Q1: Does the 75600-02 switch support waterproofing?
- A1: No, it does not include waterproof features. It is intended for indoor or protected environments.
- Q2: What is the main difference between Off-On-On-On-On and regular ON/OFF switches?
- A2: The 75600-02 provides five sequential positions, allowing multiple control states compared to standard 2-position switches.
- Q3: Can this switch handle AC voltage?
- A3: It is rated specifically for 16V DC. AC usage is not recommended unless tested and certified separately.
Conclusion
The Cole Hersee 75600-02 is a reliable, 5-position rocker switch with strong DC performance, suitable for automotive and industrial usage. Its panel mount configuration, durable design, and extended electrical life make it an excellent choice for engineers and system integrators.
Technical specifications
| Ingress Protection | - | |
| Current Rating (Amps) | 15A (DC) | |
| Depth Behind Flange | - | |
| Product Status | Active | |
| REACH Status | REACH Unaffected | |
| Electrical Life | 20,000 Cycles | |
| Mfr | Littelfuse/Commercial Vehicle Products | |
| Illumination | Non-Illuminated | |
| Features | - | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Illumination Type, Color | - | |
| Operating Temperature | - | |
| Number of Positions | 5 | |
| Termination Style | Wire Leads with Connector | |
| Approval Agency | - | |
| Panel Cutout Dimensions | - | |
| ECCN | EAR99 | |
| Circuit | - | |
| Mounting Type | Panel Mount | |
| Mechanical Life | - | |
| Illumination Voltage (Nominal) | - | |
| Series | - | |
| Type | Standard | |
| Voltage Rating - DC | 16 V | |
| Switch Function | Off-On-On-On-On | |
| HTSUS | 8536.50.9025 | |
| Package | Bulk |
