AT86RF215M-ZU (In Stock:1165)
RF Transceiver ICs Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
AT86RF215M-ZU
879-AT86RF215M-ZU
Explore the AT86RF215M-ZU from Microchip – a dual-band RF transceiver with FSK, OFDM, and O-QPSK modulation and purchase at Onzuu.
AT86RF215M-ZU Description
AT86RF215M-ZU RF Transceiver Module – Microchip
The AT86RF215M-ZU by Microchip Technology is a dual-band RF transceiver that supports both sub-1GHz and 2.4GHz ISM bands. Designed for low-power and high-performance wireless communication, it supports multiple modulation schemes including FSK, OFDM, and O-QPSK. Ideal for IoT, smart metering, and industrial applications.
Datasheet
Download the official datasheet here: AT86RF215M-ZU Datasheet
Key Features
- Dual-band RF Transceiver: Sub-1GHz and 2.4GHz
- Supports FSK, OFDM, O-QPSK Modulation
- Data Rate up to 2.4 Mbps
- High Output Power: up to 16 dBm
- Excellent Sensitivity: -123 dBm
- Low Power Consumption: 5 mA (Rx), 64 mA (Tx)
- Wide Supply Voltage: 1.8V to 3.6V
- SPI Serial Interface
Specifications
| Manufacturer | Microchip Technology |
|---|---|
| Part Number | AT86RF215M-ZU |
| Packaging | Tray |
| Status | Active |
| Type | TxRx Only |
| Frequency | 389.5MHz ~ 510MHz, 779MHz ~ 1.02GHz |
| Modulation | FSK, OFDM, O-QPSK |
| Data Rate | Up to 2.4 Mbps |
| Output Power | 16 dBm |
| Sensitivity | -123 dBm |
| Interface | SPI |
| Voltage Supply | 1.8V ~ 3.6V |
| Current (Rx/Tx) | 5 mA ~ 33 mA (Rx), 62 mA ~ 64 mA (Tx) |
| Temperature Range | -40°C ~ +85°C |
| Package | 48-VFQFN (7x7 mm) |
Application Scenarios
- Internet of Things (IoT)
- Smart Metering
- Industrial Wireless Networks
- Home Automation
- Wireless Sensor Networks
🛒 Buy AT86RF215M-ZU or Find Alternatives
Looking for AT86RF215M-ZU or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
Authorized Distributor - Onzuu
Onzuu is a professional electronic component distributor. We provide authentic Microchip parts with reliable logistics and support. Contact us to get volume pricing and delivery solutions.
Frequently Asked Questions (FAQ)
What is the max data rate of AT86RF215M-ZU?
It supports up to 2.4 Mbps data transfer rate.
Which bands does it support?
It supports Sub-1GHz (389.5–510 MHz) and 779–1020 MHz ISM bands.
What interface is used to connect it?
It uses an SPI interface for serial communication.
Is it suitable for outdoor use?
Yes, it operates in a wide temperature range from -40°C to 85°C, making it suitable for outdoor environments.
Conclusion
The AT86RF215M-ZU from Microchip is a versatile and robust RF transceiver ideal for applications in the ISM bands. Its support for multiple modulation types and high sensitivity make it an excellent choice for a wide range of wireless communication tasks. Choose Onzuu for reliable sourcing and expert support.
Technical specifications
| Serial Interfaces | SPI | |
| Product Status | Active | |
| Power - Output | 16dBm | |
| Supplier Device Package | 48-QFN (7x7) | |
| Package / Case | 48-VFQFN Exposed Pad | |
| Current - Receiving | 5mA ~ 33mA | |
| Modulation | FSK, OFDM, O-QPSK | |
| Voltage - Supply | 1.8V ~ 3.6V | |
| REACH Status | REACH Unaffected | |
| Mfr | Microchip Technology | |
| Data Rate (Max) | 2.4Mbps | |
| Protocol | - | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Transmitting | 62mA ~ 64mA | |
| ECCN | 5A992C | |
| Mounting Type | Surface Mount | |
| RF Family/Standard | General ISM < 1GHz | |
| Series | - | |
| Type | TxRx Only | |
| Sensitivity | -123dBm | |
| Memory Size | - | |
| Frequency | 389.5MHz ~ 510MHz, 779MHz ~ 1.02GHz | |
| HTSUS | 8542.39.0001 | |
| Package | Tray | |
| Base Product Number | AT86RF215 |
