KSZ8081RND-EVAL
Evaluation and Demonstration Boards and Kits Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
KSZ8081RND-EVAL
787-KSZ8081RND-EVAL
Discover the KSZ8081RND-EVAL evaluation board for Microchip's Ethernet PHY. Explore datasheets, features, specifications, use cases, purchase links, and Onzuu distributor support.
KSZ8081RND-EVAL Description
KSZ8081RND-EVAL Evaluation Board Overview
The KSZ8081RND-EVAL is an evaluation board designed by Microchip Technology for assessing the performance and capabilities of the KSZ8081RND Ethernet PHY transceiver. This board provides developers with a convenient platform to prototype and test Ethernet interfaces using the RMII protocol.
It includes RJ-45 connectors, indicator LEDs, jumpers for mode selection, and USB access for easy connectivity and diagnostics. It is ideally suited for embedded system developers working on Ethernet-enabled applications.
📄 Datasheet Module
⚙️ Features
- Supports 10Base-T/100Base-TX Ethernet standards
- Compatible with RMII interface for easy MAC integration
- Integrated HP Auto MDI/MDI-X for cable auto-sensing
- Supports Energy Efficient Ethernet (EEE) and Wake-on-LAN (WOL)
- USB interface access to MII management bus
- Jumper-configurable boot settings
- LED indicators for link status and activity
- Supports 25MHz and 50MHz RMII clock modes
📊 Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Box |
| Part Status | Discontinued at Digi-Key |
| Type | Interface |
| Function | Ethernet PHY |
| Embedded | No |
| Utilized IC / Part | KSZ8081RND |
| Primary Attributes | - |
| Secondary Attributes | - |
| Contents | Board(s) |
| Base Product Number | KSZ8081 |
🧩 Application Scenarios
- Industrial automation controllers
- IoT gateways and smart sensors
- Routers and Ethernet switches
- Networked printers and copiers
- Smart home devices
- IP phones and media boxes
🛒 Buy KSZ8081RND-EVAL or Find Alternatives
Looking for KSZ8081RND-EVAL or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
🏪 Onzuu Authorized Distributor
Onzuu is a trusted distributor of electronic components, including Ethernet PHYs like the KSZ8081 series. Our platform provides fast delivery, real-time inventory updates, and professional B2B support. Contact us to find compatible alternatives or check our inventory for this evaluation board.
Visit: www.onzuu.com
❓ Frequently Asked Questions (FAQ)
Q1: What clock modes does KSZ8081RND-EVAL support?
A1: It supports both 25MHz and 50MHz RMII clock modes via jumper settings.
Q2: Can I access the MII bus via USB?
A2: Yes, using Microchip’s SwitchPhyTools software over USB.
Q3: Does it support cable auto detection?
A3: Yes, the HP Auto MDI/MDI-X function supports automatic detection of straight/crossover cables.
Q4: What are the power supply options?
A4: The board can be powered via the MII connector or USB port with +5V DC.
Q5: Is it compatible with other KSZ8081 series chips?
A5: It is tailored for KSZ8081RND. Compatibility with other models like KSZ8081RNA may vary.
✅ Summary
The KSZ8081RND-EVAL is a versatile and practical evaluation tool for developers working with Microchip’s KSZ8081RND Ethernet PHY. It provides an effective way to explore RMII-based Ethernet solutions in embedded designs. Although discontinued from some suppliers, alternatives and replacements are still available through authorized distributors like Onzuu.
