NJM2211D
RF Demodulators Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
NJM2211D
878-NJM2211D
Discover detailed specifications, datasheet, features, and applications of the NJM2211D dual operational amplifier. Find reliable purchasing options including Onzuu distributor.
NJM2211D Description
The NJM2211D is a demodulator IC manufactured by Nisshinbo Micro Devices Inc. It comes in a 14-pin DIP through-hole package and operates with a supply voltage range from 4.5V to 20V. Although currently obsolete, it has been widely used in RF demodulation applications. The device draws a supply current of 11 mA, suitable for various legacy communication equipment.
β Datasheet
π Download NJM2211D Datasheet
The datasheet includes technical drawings, installation instructions, and environmental ratings.
Features
- Demodulator function
- Wide supply voltage range: 4.5V to 20V
- Supply current: 11 mA
- Through-hole mounting type
- 14-pin DIP package (0.300" / 7.62mm)
- Obsolete part status
Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Packaging | Tube |
| Part Status | Obsolete |
| Function | Demodulator |
| Supply Current | 11 mA |
| Supply Voltage | 4.5V ~ 20V |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
Applications
The NJM2211D is mainly used in radio frequency demodulation circuits and legacy communication devices requiring signal extraction. Its obsolete status means it is mostly found in repair and maintenance of older systems.
π Buy NJM2211D or Find Alternatives
Looking for NJM2211D or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
Onzuu Distributor Recommendation
Onzuu is a trusted electronic component distributor offering genuine and legacy parts like the NJM2211D. Customers enjoy flexible order quantities, reliable supply, and responsive service, making Onzuu the ideal partner for legacy and active components.
FAQ
- Q: Is the NJM2211D still in production?
A: No, it is classified as obsolete. - Q: What is the supply voltage range for NJM2211D?
A: 4.5V to 20V. - Q: What package does the NJM2211D use?
A: 14-pin DIP, through-hole mounting. - Q: Can Onzuu provide replacement parts?
A: Yes, Onzuu can assist in finding suitable alternatives.
Summary
The NJM2211D demodulator IC from Nisshinbo Micro Devices Inc. is a legacy component widely used in RF demodulation applications. Though now obsolete, it features a wide supply voltage range and a reliable through-hole DIP package. Onzuu remains your trusted partner for sourcing NJM2211D and related legacy components.
Technical specifications
| ECCN | EAR99 | |
| Mounting Type | Through Hole | |
| Current - Supply | 11 mA | |
| Product Status | Obsolete | |
| Supplier Device Package | 14-DIP | |
| Series | - | |
| Function | Demodulator | |
| RF Frequency | - | |
| Package / Case | 14-DIP (0.300", 7.62mm) | |
| Voltage - Supply | 4.5V ~ 20V | |
| REACH Status | REACH Unaffected | |
| Mfr | Nisshinbo Micro Devices Inc. | |
| P1dB | - | |
| Noise Figure | - | |
| HTSUS | 8542.39.0001 | |
| Package | Tube | |
| LO Frequency | - | |
| Gain | - | |
| RoHS Status | RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
