STGAP2SICSNTR (In Stock:10)
Isolators - Gate Drivers Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
STGAP2SICSNTR
906-STGAP2SICSNTR
Explore the features, specifications, applications, and datasheet of STGAP2SICSNTR - a single-channel isolated SiC MOSFET gate driver IC by STMicroelectronics.
STGAP2SICSNTR Description
STGAP2SICSNTR Gate Driver Overview
The STGAP2SICSNTR is an advanced, single-channel, isolated gate driver from STMicroelectronics, tailored for SiC MOSFET control. Leveraging capacitive coupling technology, it ensures 4000Vrms isolation and offers fast switching with 4A peak output. This gate driver is perfect for high-performance, high-voltage power conversion applications such as EV charging stations, inverters, motor drives, and industrial automation.
✅ Datasheet
Download STGAP2SICSNTR Datasheet (PDF)
✅ Features
- Capacitive isolation with 4000Vrms withstand voltage
- 4A peak source/sink current capability
- High CMTI: 100V/ns minimum
- Fast switching: 90ns propagation delay
- Low pulse width distortion: 20ns max
- Surface-mount SO-8 package
- Operating temperature: -40°C to +125°C (TJ)
- UL certified
✅ Specifications
| Parameter | Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Part Number | STGAP2SICSNTR |
| Technology | Capacitive Coupling |
| Channels | 1 |
| Isolation Voltage | 4000Vrms |
| CMTI (min) | 100V/ns |
| Propagation Delay | 90ns (typ) |
| Pulse Width Distortion | 20ns (max) |
| Rise/Fall Time | 30ns |
| Peak Output Current | 4A |
| Output Supply Voltage | 16.4V ~ 26V |
| Mounting | Surface Mount |
| Package | SOIC-8 |
| Status | Active |
| Temperature Range | -40°C to +125°C |
| Approval | UL |
✅ Applications
- Electric Vehicle (EV) chargers
- High-efficiency power inverters
- Industrial motor drivers
- Solar inverters and UPS systems
- High-voltage DC-DC converters
🛒 Buy STGAP2SICSNTR or Find Alternatives
Looking for STGAP2SICSNTR or equivalent parts? Contact Onzuu, your trusted electronic component distributor. We offer sourcing, BOM services, and global delivery.
✅ Onzuu Authorized Distributor
Onzuu is your reliable electronic component distributor offering authentic STMicroelectronics parts including STGAP2SICSNTR. We support bulk orders, fast delivery, and competitive pricing for OEMs and manufacturers globally.
✅ ✅ ✅ Frequently Asked Questions (FAQ)
- Q1: What makes STGAP2SICSNTR suitable for SiC MOSFETs?
A: It features high CMTI (100V/ns), strong drive current (4A), and wide output voltage, ideal for SiC gate control. - Q2: Can I use this gate driver in automotive designs?
A: Yes, it is rated for high reliability and extended temperature ranges, suitable for demanding environments. - Q3: What is the difference between STGAP2SICSN and STGAP2SICSNTR?
A: The "TR" suffix indicates tape & reel packaging for automated assembly.
✅ Summary
The STGAP2SICSNTR is a robust, high-performance SiC gate driver IC designed for industrial and automotive-grade applications. With strong isolation, high drive capability, and fast response, it offers a reliable solution for demanding power electronics systems.
Technical specifications
| Rise / Fall Time (Typ) | 30ns, 30ns | |
| Common Mode Transient Immunity (Min) | 100V/ns | |
| Current - Peak Output | 4A | |
| Product Status | Active | |
| Supplier Device Package | 8-SO | |
| Pulse Width Distortion (Max) | 20ns | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Number of Channels | 1 | |
| Technology | Capacitive Coupling | |
| REACH Status | REACH Unaffected | |
| Voltage - Output Supply | 16.4V ~ 26V | |
| Mfr | STMicroelectronics | |
| Voltage - Forward (Vf) (Typ) | - | |
| Propagation Delay tpLH / tpHL (Max) | 90ns, 90ns | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Voltage - Isolation | 4000Vrms | |
| Approval Agency | UL | |
| ECCN | EAR99 | |
| Mounting Type | Surface Mount | |
| Series | - | |
| HTSUS | 8542.39.0001 | |
| Package | Tape & Reel (TR) | |
| Base Product Number | STGAP2 | |
| Current - Output High, Low | 4A, 4A |
