XDCAH50M850PHA00P0 (In Stock:2719)
Monolithic Crystals Manufacturer:
Mfr. Part #:
onzuu Part #:
Datasheet:
Description:
XDCAH50M850PHA00P0
847-XDCAH50M850PHA00P0
Get complete details for XDCAH50M850PHA00P0: datasheet, electrical specs, compatible alternatives, and available distributors with global shipping.
XDCAH50M850PHA00P0 Description
XDCAH50M850PHA00P0 Product Overview
1. Product Overview – XDCAH50M850PHA00P0
Manufacturer: Murata Electronics
Series: XDCAH
Packaging: Tape & Reel (TR), Cut Tape (CT)
Part Status: Obsolete
Key Specifications:
- Center Frequency: 50.85 MHz
- Impedance: 560 Ohms
- Insertion Loss: 5 dB
- Bandwidth: 5 kHz
- Ripple: 1 dB
- Number of Poles: 4
- Operating Temperature: -20°C to +70°C
Mechanical Details:
- Mounting Type: Surface Mount
- Package / Case: 6-SMD, No Lead
- Dimensions: 0.276" L x 0.197" W (7.00mm x 5.00mm)
- Height (Max): 0.049" (1.25mm)
Download Datasheet:
For detailed electrical characteristics, test circuits, and application notes, download the full datasheet of XDCAH50M850PHA00P0:
Looking for XDCAH50M850PHA00P0 replacement or datasheet? Contact Onzuu for sourcing discontinued Murata components with fast shipping options worldwide.
Inquire Now2. Product Image
Illustrative image of XDCAH50M850PHA00P0 – for reference only
3. Alternative Parts / Cross References
- XDCAH50M850PHA00P1 – Similar specs, RoHS-compliant version
- DFCD5008550HDHP-TL – Murata ceramic filter with tighter bandwidth
- LFD21860MNFC119 – Murata high-frequency filter, 60 MHz center
- Contact Onzuu for compatible replacement sourcing
XDCAE50M000HHA01P0 XDCAF21M400RAA00P0 XDCAF21M700MAA00P0 XDCAG38M850PGA00P0 XDCAG45M000RGA00P0 XDCAG46M350PGA00P0 XDCAG49M950PGA00P0 XDCAG51M650PGA00P0 XDCAG58M050MGA00P0 XDCAH25M000EHA01P0 XDCAH50M850PHA00P0 XDCAH73M350QHA03P0
| Part Number | Manufacturer | Series | Center Frequency | Mounting Type | Status | Datasheet |
|---|---|---|---|---|---|---|
| XDCAE50M000HHA01P0 | Murata Electronics | XDCAE | 50.00 MHz | Surface Mount | Active | Download |
| XDCAF21M400RAA00P0 | Murata Electronics | XDCAF | 21.40 MHz | Surface Mount | Active | Download |
| XDCAF21M700MAA00P0 | Murata Electronics | XDCAF | 21.70 MHz | Surface Mount | Active | Download |
| XDCAG38M850PGA00P0 | Murata Electronics | XDCAG | 38.85 MHz | Surface Mount | Active | Download |
| XDCAG45M000RGA00P0 | Murata Electronics | XDCAG | 45.00 MHz | Surface Mount | Active | Download |
| XDCAG46M350PGA00P0 | Murata Electronics | XDCAG | 46.35 MHz | Surface Mount | Active | Download |
| XDCAG49M950PGA00P0 | Murata Electronics | XDCAG | 49.95 MHz | Surface Mount | Active | Download |
| XDCAG51M650PGA00P0 | Murata Electronics | XDCAG | 51.65 MHz | Surface Mount | Active | Download |
| XDCAG58M050MGA00P0 | Murata Electronics | XDCAG | 58.05 MHz | Surface Mount | Active | Download |
| XDCAH25M000EHA01P0 | Murata Electronics | XDCAH | 25.00 MHz | Surface Mount | Obsolete | Download |
| XDCAH50M850PHA00P0 | Murata Electronics | XDCAH | 50.85 MHz | Surface Mount | Obsolete | Download |
| XDCAH73M350QHA03P0 | Murata Electronics | XDCAH | 73.35 MHz | Surface Mount | Active | Download |
Technical specifications
| Insertion Loss | 5dB | |
| Operating Temperature | -20°C ~ 70°C | |
| ECCN | EAR99 | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Height (Max) | 0.049" (1.25mm) | |
| Product Status | Obsolete | |
| Frequency - Center | 50.85 MHz | |
| Series | XDCAH | |
| Package / Case | 6-SMD, No Lead | |
| Bandwidth | 5 kHz | |
| Mfr | Murata Electronics | |
| Ripple | 1dB | |
| Number of Poles | 4 | |
| HTSUS | 8541.60.0020 | |
| Package | Tape & Reel (TR) | |
| Impedance | 560 Ohms | |
| RoHS Status | ROHS3 Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
