Here’s a practical, “from blank board to production” blueprint for data storage & management on embedded systems. Skim the bold headings first; dive where you need details.

1) Start with a data brief (5 questions)

Write this down before you pick any tech:

• What do you store? (configs, logs, sensor data, ML params, firmware)

• How much total and per write? (bytes…MB)

• How often do you write? (Hz / per day)

• How long must it survive power-offs & heat? (retention, temp)

• How safe must it be? (integrity, security, regulatory)

2) Pick the memory technology

3) Decide the storage topology

• Raw flash (NOR/NAND) → FTL/wear-level → FS or KV store

• Managed media (eMMC/SD) → FS directly (FAT/ext/F2FS)

• NVRAM (FRAM/MRAM) → raw records / KV (no FTL needed)

Use a partition map (even on MCUs):

• bootloader | fw_A | fw_B (OTA) | factory_cal | kv_config | logs | user_data

4) Filesystem vs Key-Value vs Raw

Key-Value (KV) store (recommended for configs)

• Pros: tiny footprint, atomic, easy wear leveling.

• Examples: littlefs (has directories + KV style), ESP-IDF NVS, Zephyr settings, STM32 EEPROM emulation app notes.

Filesystems

• littlefs (NOR): copy-on-write, power-fail safe, great for ≤16 MB.

• SPIFFS (NOR): lightweight; no directories; aging project.

• FAT/exFAT (SD/eMMC): ubiquitous & PC-friendly; add journaling layer for power-fail safety.

• UBIFS/YAFFS2 (raw NAND, Linux): handle bad blocks & wear leveling.

• F2FS/ext4 (eMMC/UFS, Linux): log-structured/ext with journaling.

Raw append-only logs / ring buffers

• Best for telemetry and black-box logs; you manage indexing, CRC, rollover.

5) Wear leveling & endurance

• Never update-in-place on flash sectors; use copy-on-write or log-structured writes.

• Rotate erase blocks (dynamic leveling). Keep hot data (counters) in FRAM if possible.

• Budget writes against endurance (e.g., 50–100k P/E NOR; eMMC/NAND varies by grade).
  Tip: move high-churn data (e.g., uptime counters) to FRAM or to a journal page that rotates.

6) Data integrity: make corruption boring

• Per-record CRC/CRC32 (or AEAD tag if encrypted).

• Atomic commit pattern: write header → data → CRC → flip commit bit/sequence.

• Prefer journaling / copy-on-write FS (littlefs, UBIFS, ext4 journaled).

• Add ECC where available (BCH/LDPC in NAND, eMMC controller built-in).

7) Power-fail safety

• Keep writes small and bounded; avoid multi-page “transactions”.

• Use double buffering or A/B records with monotonically increasing version/counter.

• Hardware assists: brown-out reset (BOR), PMIC POK, optional supercap to flush last block.

• Test with yank-the-plug campaigns at random write times.

8) Concurrency & RTOS integration

• Use a single storage task with a message queue (producer/consumer); it serializes access.

• Gate the block device with a mutex; keep critical sections short.

• Use DMA for SD/eMMC; align buffers to cache lines; flush/invalidate caches on MMU systems.

9) Performance & footprint

• Batch tiny writes into a write buffer (e.g., 512–2048 bytes).

• Choose page/sector-aligned structures; avoid read-modify-erase loops.

• Keep FS cache small but nonzero; e.g., littlefs block cache = 1–4 blocks.

10) Security (when data matters)

• Secure boot for firmware partitions; rollback protection (monotonic counter).

• Encryption at rest for sensitive data: AES-GCM/XTS, keys in HUK/PUF/TPM/TrustZone.

• Per-record nonce + auth tag; consider key rotation and sealed storage APIs (TEE).

11) OTA & versioned data

• Use A/B firmware slots + small boot control KV with a trial-boot flag.

• Store schema version with each dataset; include migrations on upgrade.

• Keep factory calibration in a protected, rarely-erased area.

12) Data formats that work on MCUs

• TLV (Type-Length-Value): tiny and robust.

• CBOR (small, self-describing) or protobuf-nano/flatbuffers for bigger MCUs.

• Always pack a magic, version, length, CRC, timestamp.

Minimal, robust patterns

A) Power-safe KV record (copy-on-write on NOR/FRAM)

Recovery: scan from the end; last record with valid CRC and commit mark wins.

B) Ring logger (fixed-size records)

C) LittleFS on external QSPI NOR (bare-metal sketch)

• Partition NOR into lfs area (multiple erase blocks).

• Mount with small caches and wear-level config; store configs in a single JSON/TLV file; logs in /log/ rolling files.

Platform hints (common stacks)

• STM32 (bare-metal/FreeRTOS): FATFS + wear-level for SD/eMMC; ST app notes for EEPROM emulation in Flash; littlefs via CubeMX middleware or open-source ports.

• ESP32: NVS (KV store) on SPI flash; FATFS with wear-leveling driver; OTA with A/B provided by ESP-IDF.

• Zephyr RTOS: settings (KV on NVS), littlefs/fcb (flash circular buffer), mcuboot for secure A/B OTA.

• Linux SBC (e.g., i.MX, Zynq): ext4/F2FS on eMMC; UBIFS on raw NAND; use journald or your own ring logger for telemetry.

Validation & test checklist

• Endurance plan: compute estimated daily writes vs device P/E and confirm margin.

• Power-pull tests: hundreds of random pulls during active writes; zero-brick criteria.

• Fault injection: flip bits in staged images, corrupt CRCs, simulate bad blocks.

• Aging/thermal: soak tests at temperature corners; verify retention & boot times.

• Security tests: verify rollback protection, key sealing, and tamper responses.

• Field telemetry: include counters (erase cycles, mount failures, recovery count).

Quick decision guide

• Just configs, rare writes: NVS/KV on internal flash (wear-leveled) → done.

• Configs + small logs, power-safe: littlefs on QSPI NOR + ring logger.

• Lots of data or high write rate: eMMC/SD with ext4/F2FS (Linux) or FAT + journaling layer (RTOS) + periodic checkpoints.

• High-churn tiny writes: add FRAM/MRAM for hot variables; keep flash for bulk.
