Application of Magnetic Devices in Automotive OBC

Here’s a concise, engineer-focused guide to how magnetic devices are applied inside an automotive On-Board Charger (OBC)—what each part does, what to watch for, and how to size/choose them.

1) OBC power path (where magnetics live)

AC In → EMI Filter (CM choke, X/Y caps, DM choke) → PFC (boost or bridgeless totem-pole) → HV DC Link → Isolated DC/DC (LLC or PSFB) → Battery Output Filter → Vehicle HV bus

Magnetics show up in bold places:

• Input EMI: Common-mode (CM) choke, differential-mode (DM) choke.

• PFC stage: Boost inductor (or interleaved/coupled inductors in totem-pole).

• Isolation stage: High-frequency transformer (LLC or PSFB) and resonant inductor (LLC) or output filter inductors (PSFB).

• Aux supplies: Small flyback transformer for housekeeping rails.

• Sensing/communications: Current transformers/Hall cores, signal magnetics (CAN/LIN/Ethernet chokes).

2) What each magnetic component does (and key specs)

3) Materials & construction choices

• Ferrite (MnZn/NiZn): Low core loss at 50–300 kHz; use gaps for energy storage (PFC/output ind.).

• Powdered iron (Fe-Si-Al, Fe-Si): Excellent DC-bias tolerance, broader loss curve; good for output inductors.

• Nanocrystalline/Amorphous: Very high permeability; great for CM chokes (compact, high L_CM), also current transformers.

• Planar magnetics: PCB-embedded windings + low profile cores (E-/EQ-/ER-/PQ-planar). Boosts power density, repeatability, cooling via PCB copper; watch proximity losses and insulation stack-up.

• Litz wire: Reduces skin/proximity loss as you push >100 kHz with SiC/GaN. Choose strand dia to ≈ skin depth at f_sw.

4) Safety & compliance (automotive specifics)

• AEC-Q200 (passives): thermal shock, vibration, humidity, life.

• Isolation & insulation: Reinforced isolation for the transformer; creepage/clearance per working voltage, pollution degree, CTI group (follow IEC 60664-1 methodology). Use triple-insulated wire, margins or tapes; perform partial discharge tests (PDIV > worst-case).

• EMC: CISPR 25 (vehicle), ISO 7637-2 (transients), OEM specs (e.g., LV123/LV124/LV148). Magnetics must support conducted/radiated limits (design CM/DM impedance accordingly).

• Functional Safety: ISO 26262—magnetic sensors for current/voltage paths often feed safety functions (redundancy, diagnostics).

• Thermal robustness: −40…125/150 °C ratings, potting/impregnation to mitigate vibration and noise (magnetostriction).

5) Quick sizing heuristics & equations

5.1 PFC boost inductor (continuous conduction)

Target inductor ripple ΔI ≈ 20–40% of I_L at nominal line.

5.2 LLC transformer & resonant elements

Normalize to

• Choose turns ratio $n$ from target battery voltage range and expected gain window around f0f_0f0​.

• Leakage inductance provides L_r; tune via spacing/shields/gaps.

• Keep magnetizing inductance L_m​ typically 3–8× L_r​ to secure ZVS and light-load behavior.

• Use core loss curves at operating flux (keep ΔB modest at high f_sw).

• For planar, estimate AC resistance (R_ac) with Dowell/IEC methods; consider interleaving for lower leakage.

5.3 Output inductor (PSFB or secondary filters)

​​

• Choose core with good DC bias (powder/gapped ferrite), size DCR for ≤1–2% efficiency hit.

6) EMI filter strategy that actually works

1. Front CM choke sized so CM impedance peaks where switching noise converts to line.

2. Small DM choke + X caps (X2 at AC input, film cap across PFC) to hit DM noise.

3. Y caps sized for EMI but within leakage current limits (charging standards).

4. Shield/aux windings on the transformer can reduce CM emission (careful with capacitance to primary).

5. Snubbers/RCD/RC-dampers tame ringing that magnetics + parasitics form.

7) Reliability & mechanical

• Potting/impregnation to reduce audible noise and improve heat spreading; verify resin coefficients to avoid cracking cores.

• Tape systems (e.g., polyimide) with certified build; margin tape for creepage on PCB edges.

• Mounting: tie-downs, glue fillets, and center-leg clamps on E/PQ cores for vibration.

• Thermal: provide copper planes/vias below planar magnetics; consider heat spreaders for >2–3 W core+copper loss.

8) Practical part selection checklist

• PFC inductor: L at bias & temp, A_L tolerance, core loss @ f_sw, litz or multi-filar, gapped ferrite (E/PQ/ER), DCR ≤ few mΩ.

• CM choke: nanocrystalline for compact size, verify saturation with inrush, temperature rise at worst ambient.

• LLC transformer: reinforced isolation, triple-insulated wire or certified tape stack, designed leakage for Lr, planar if height-limited.

• Output inductor: powder or gapped ferrite, ΔI target, thermal rise <40–50 K at full load.

• Current sense: Hall core for DC, CT for AC ripple; ensure bandwidth and linearity.

• Aux flyback: keep C_parasitic low to reduce CM coupling; shield winding if needed.

Example: 3.3 kW single-phase OBC (totem-pole + LLC)

• f_sw(PFC) = 100–140 kHz (SiC/GaN), interleaved; choose coupled inductors to halve ripple.

• f_sw(LLC) ≈ 140–220 kHz; planar transformer with targeted leakage for LrL_rLr​, litz on discrete builds.

• CM choke ~10–30 mH (nanocrystalline) sized for current & temp; DM choke a few 10s–100s µH.

• Output inductor (if PSFB or post-filter in LLC) sized for ≤20–30% ripple at nominal battery voltage.

Common pitfalls (avoid these)

• Using catalog L at 25 °C—inductor saturates hot at low line.

• Ignoring proximity loss—planar looks great in DC but runs hot at HF.

• Transformer isolation stack-up fails PD/hipot due to an overlooked margin or via clearance.

• CM choke saturates under inrush (or DC bias in bridgeless topologies).

• Oversized Y-caps blowing leakage current limits for charging standards.

Deliverables I can provide next

• A quick PFC/LLC magnetic pre-size sheet (inputs: power, Vin range, Vbat range, f_sw).

• Planar stack-up sketch with interleaving order and expected leakage.

• EMI filter first-cut (CM/DM) for your target power and switching frequency.
